Camera Specifications
Image Sensor
1/2.7″ CMOS
Effective Pixels
1920(H)×1080(V), 2MP
Scanning System
Progressive
Electronic Shutter Speed
PAL: 1/25~1/100000s
NTSC: 1/30~1/100000s
Minimum Illumination
0.04Lux/F1.85, 30IRE, 0Lux IR on
S/N Ratio
More than 65dB
IR Distance
Up to 20m (66feet)
IR On/Off Control
Auto / Manual
Lens
Lens Type
Fixed lens / Fixed iris
Mount Type
Board-in
Focal Length
3.6mm (2.8mm, 6mm Optional)
Max Aperture
F1.85
Angle of View
H: 93° (103°, 54.7°)
Focus Control
N/A
Close Focus Distance
800mm (2000mm)
31.50” (78.74”)

Resolution
1080P (1920×1080)
Frame Rate
25/30fps@1080P, 25/30/50/60fps@720P
Video Output
1-channel BNC high definition video output / CVBS video output (Can switch)
Day/Night
Auto (ICR) / Manual
OSD Menu
Multi-language
BLC Mode
BLC / HLC / DWDR
WDR
DWDR
Gain Control
AGC
Noise Reduction
2D
White Balance
Auto / Manual
Smart IR
Auto / Manual
Casing: Plastic
